ISA5208 Solid shaft diameter 8mm; outside diameter 52mm; Encoder with meter wheel
Minature size,easy assembling
2 quadrature output channel (A&B) + index signal
Resolution up to 3600cpr
Housing size 52mm, shaft dia. 8mm
online service
ISA5208 Solid shaft diameter 8mm; outside diameter 52mm; Encoder with meter wheel
Features
● Minature size,easy assembling
● 2 quadrature output channel (A&B) + index
signal
● Resolution up to 3600cpr
● Housing size 52mm, shaft dia. 8mm
· Model: ISA5208
· Brand: YUMO
· Code: YM00000017
Feature
A rotary encoder, also called a shaft encoder, is an electro-mechanical device that converts the angular position or motion of a shaft or axle to an analog or digital code.
There are two main types: absolute and incremental (relative). The output of absolute encoders indicates the current position of the shaft, making them angle transducers. The output of incremental encoders provides information about the motion of the shaft, which is typically further processed elsewhere into information such as speed, distance and position.
Application
Rotary encoders are used in many applications that require precise shaft unlimited rotation—including industrial controls, robotics, special purpose photographic lenses,computer input devices (such as optomechanical mice and trackballs), controlled stress rheometers, and rotating radar platforms.
Welcome to our website! Please send your words at any time in the following form and ask us, we will contact you and provide you with the corresponding service as soon as possible. Please write in English.
6mm 24VDC shaft incremental encoder E6B2-CWZ6C Rotary Encoder
Good reliability, long life, anti-jamming performance.
Stainless steel shaft has a higher stability and protection.
Metal shell is more solid and anti-impact.
Bearing load heavy, anti-oil and water.
Applicability to a wide variety of mechanical and industrial control.
ISC3808-001G-100ABZ3-5-30E rotary shaft encoder
Miniature size, easy assembling
2 quadrature output channel (A&B) + index signal
ISC2504-001E-200B-5C shaft diameter 4mm 5VDC Solid Shaft Incremental Rotary Encoder
◆ Features
● Miniature size, easy assembling
● 2 quadrature output channel (A&B) + index signal
● Housing size 25mm, shaft dia. 4mm
ISC3806 series Outer diameter 38mm Solid Shaft Incremental Rotary Encoder
Feature
A rotary encoder, also called a shaft encoder, is an electro-mechanical device that converts the angular position or motion of a shaft or axle to an analog or digital code.
There are two main types: absolute and incremental (relative). The output of absolute encoders indicates the current position of the shaft, making them angle transducers. The output of incremental encoders provides information about the motion of the shaft, which is typically further processed elsewhere into information such as speed, distance and position.
